ML-2550A_ML-2551A_ML-2552A_ML-2650B_ML-2651B

Well-equipped features and high-power enable high-speed and high-quality welding!
Model : ML-2550A_ML-2551A_ML-2552A_ML-2650B_ML-2651B

Welding with a few heat-affected area can be done due to that laser welding is "contactless" welding.

Real-time Power Feedback feature ensures stable welding under optimum weld conditions.

Employing an optical fiber makes its automation easy.

High power oscillator enables high speed seam welding.

Up to four energy sharing.

Controller is detachable.

 Real-time Power Feedback Control

The laser output in the lamp-pumped module is monitored in real time. The monitored laser output is compared with the set waveform and power is fed back in real time, varying the energy input to the lamp to reproduce the set waveform and obtain the ideal laser output waveform.




 Variable mirrors

These mirrors eliminate laser power loss and improve branch balance.


 Waveform control

Equipped with a "fixed mode" that features three-level waveforms, and a "flex mode" to provide more complex waveforms.

 Power monitor

Laser energy (J) and average power (W) are monitored to detect abnormalities.

 Controller

The controller can be detached from the main unit to operate at your hand.


 External communications
Configuration of parameters and monitoring of performance can be carried out from a separate location.
- Type: RS-485 compliant, asynchronous, full duplex
- Data speed: 9600, 19200, 38400 bps
 Fade-in/Fade-out

This feature avoids marks at the end of seam welding and provides a beautiful finish even for overlapping circumference seam welding sections.

Model ML-2550A ML-2551A ML-2552A ML-2650B ML-2651B
Oscillation wavelength 1064nm
Maximum average power 400W 300W 300W*1 600W 500W
Maximum output energy 80 J/P (Pulse width 10ms) 50 J/P (Pulse width 10ms) 20 J/P (Pulse width 4ms) 100 J/P (Pulse width 10ms) 80 J/P (Pulse width 10ms)
Pulse width Standard: 0.3 to 100.0 ms (0.1 ms steps)
Fine setting: 0.25 to 5.00 ms (0.05 ms steps)
Pulse repetition 1 to 500pps
Fiber optic delivery Up to 4 deliveries of laser output are available including powersharing and timesharing. (optional)
External datacom RS-485
Power requirements 3-phase, 200, 240, 380, 400 V AC±10%, 50/60Hz
3-phase, 220 V AC+10%-15%, 50/60Hz(Tap switching)
Cooler Heat exchange method Water - Water
Required city water Pressure: 294kPa (3kgf/cm²) maximum
Water temperature: 5° to 35°C
Flow rate: 16 litter/min at 30°C
25 litter/min at 35°C
Flow rate: 25 litter/min at 25°C
55 litter/min at 32°C
Differential pressure: 98 to 294kPa (1 to 3kgf/cm²)
Inner diameter of hose Φ15mm Φ19mm
  When chiller is employed, cooling capability of 11.8 kW (10150kcal/h) is required for the chiller cooler When chiller is employed, cooling capability of 23.5kW(20160 kcal/h) is required for the chiller cooler maximum
Dimensions 530(W) X 1,347(D) X 1,170(H)mm 550(W) X 1,780(D) X 1,200(H)mm
Weight Approx. 400 kg (at 220, 240 V AC),
Approx. 450 kg (at 380 V AC)
540kg
  • *1: Value in case of when pulse width is set between 0.8 and 15.0ms and when peak power is over 1.5W. When it is not under this condition, maximum power is 250W.

Specifications subject to change without notice.

 Dimensions in mm








27.jpg 21.jpg
Cigarette lighter Gimbals Optic connector
22.jpg 30.jpg 29.jpg
Motor core Transformer core Transformer core

26.jpg 23.jpg 24.jpg 28.jpg
Titanous body Discharge valve Motor Lithium-ion battery
